Description
Elevate your woodworking capabilities with the KING CANADA KC‑520C 20″ Industrial Planer, a durable and high-performance machine built for precision and reliability. Powered by a robust 5 HP motor, it features cast-iron extension tables and an integrated mobile base for both stability and mobility. The 4-knife cutterhead ensures rapid material removal while delivering a superior finish, and the work table rises and lowers on four precision-ground columns for maximum accuracy. Safety is enhanced with anti-kickback fingers at the infeed and a magnetic safety switch, while a gear-shifting lever allows you to adapt feed rates for soft or hard woods. Its cutterhead knives are secured via adjustable jack screws with lock bar, and it comes complete with a knife-setting gauge and 5″ dust chute for efficient setup and clean operation.
Features
- Powerful 5 HP motor
- Solid cast-iron extension tables
- Mobile base system built into cabinet
- 4 knife cutterhead allows rapid cutting while producing a superior finish
- Table raises and lowers on four precision ground columns for extra stability
- Anti-kickback fingers in front of the infeed roller prevents wood kickback
- Magnetic safety switch
- Lever allows you to shift gears for changing feed rates for excellent results in planing hard and soft woods
- Knives rest on adjustable Jack Screws; lock bar and lock screws keep knives in place
- Comes with knife setting gauge and 5″ dust chute
Specifications
- Maximum planing width: 20″
- Maximum planing thickness: 8″
- Maximum depth of cut: 3/32″
- Total surface of work table: 56-1/2″ x 20″
- Cutterhead speed: 5,000 rpm
- Cutterhead diameter: 3.15”
- Number of knives: 4
- Feed rate: 2 (16-20) fpm
- Number of cuts per inch: 104-83
- Motor: 19 amp.
